EMAX Industrial 7.5HP 31CFM 1-Phase 2 Stage 80 gal.Vertical Stationary Electric Air Compressor-w/Pressure Lube Pump,w/Isolator Pads

EMAX

Pressure Lube

Pressure Lubrication is the second type of lubrication systems. This system is more technically advanced and a far more precise method to deliver oil to critical parts of the pump, resulting in longer pump life. The oil is pumped through an oil filter and into the pump where it is then recycled and reused. Since the oil pump is delivering the oil more efficiently the viscosity of the oil is less critical than with a splash system. In the air compressor industry, it is typically more costly to upgrade to pressure lubrication systems. *Our high efficiency manufacturing facility 0to the tank. With this radiator, we target outlet air to the tank within 10 degrees of ambient temperature.


Belt Drive

Our belt driven compressors are driven by V belts that allow you to adjust the pump speeds by changing pulley sizes.



SKU: EI07V080V1 Categories: , ,
Weight 848 lbs
Brands

EMAX

HP

7.5

Tank Size

80

Voltage +/- 10%

230

Phase

1

Drive Type

Electric

Tank Drain

Manual

Pump Type

Pressure

CFM

31

Silent Air

N

Smart Air

N

Compressor Type

Piston

Motor Type

ODP

Tank Orientation

Vertical

Duty Cycle

0.6

Outlet Size

3/4"

Belt Count

2

Pump Stage

2

Pump Model

APP4V1043TP

Pump Riser

N

Belt Tensioner

N

Mag Starter

Y

Radiator

N

Continuous Run

N

Peak Starting Amps

210

CFM At Max PSI

26

Pump RPM

590

Motor RPM

1740

FLA + 1.15 Service Factor

38.9

Locked Rotor Amps

210

Max PSI

175

Uncrated Weight

662

Crated Weight

811

Uncrated Length

37

Uncrated Width

25

Uncrated Height

75

Crated Length

48"

Crated Width

46"

Crated Height

87"

Oil Capacity

2

Oil U/M

Quarts

Start Type

FIXED

Estimated Pump Life (Hours)

70000

Certifications

ETL,ASME,CRN

Service Kit

EFKIT008WBS
